Case:              Ø3"(80mm),black steel

Bezel:              Screw, chrome steel

Window:          Glass with red triangle

Pointer:           Black aluminium

Dial:                 Aluminium

Bourdon tube: Phosphor bronze

Movement:      Brass

Wetted parts:  Brass

Type:              Center back or bottom entry

Union:             1/2 NPT

Length:           2"(50mm)

Accuracy:        Pressure:±2.5%,Temperature:±2% of full scale

Scale:             Single or double scales

Pressure range:    0-75psi/kPa, 0-100psi/kPa, 0-200psi/kPa

Temperature range:   30-240°F/0-115°C
